Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Appendix A EMC Installation Guide
casing of elevator integrated drive controller. If impractical, firstly strand both shielding layers as
short and wide braid, and then flatten it to facilitate connecting to the PE terminal of elevator
integrated drive controller. The uncovered section of cable core conductor and the PE soft braid
lead shall be as short as possible within 15cm.
⑸ Keyboard cable shall not be threaded out from the shielding cabinet.
The slot holes on shielding cabinet shall be as small as possible within 15cm in length.
A10 EMC Conformity
The AS380 series elevator integrated drive controller conforms to the EMC directive as shown by
attached Table A10.1 provided that suitable input/output filters and AC reactors (see ―Optional
Parts‖ for the type of optional filters and reactors) and installed and the above-said precautions are
carefully taken.
Table A10.1 General EMC Performance of AS380-series Elevator Integrated Drive Controller
Conducted noise emission
immunity
0.15<0.50MHz, 100db (/m) quasipeak
0.50<5.0MHz, 86db (/m) quasipeak
5.0<30MHz, 90:70db (/m) quasipeak
Radiated noise emission
immunity
30<230MHz, 40db (/m) quasipeak
230<1000MHz, 47db (/m) quasipeak
Electrostatic discharge noise
immunity
Criterion B(contact discharge 4000V, air
discharge 8000V)
Radiated electromagnetic
field noise immunity
Level 3, criterion A(3V/m)
Level 4, Criterion B(heavy voltage end
±2KV/2.5kHz)
Criterion A (3V,0.15～80MHz)
