Chapter 6 Introduction to the supporting products
112
Port
Point
Definition
Remark
2
Input HX11，backup
3
JP4.1-JP4.2 Input common port,0V
JP5
1
Input HX12，backup
2
JP5.1 Input common port,0V
Note: Thouth the same definitions for front door output of JP7, JP8, JP8 on SM.09IO/B board can be found
in that of the SM.02/H board, the related front door definitions (optocoupler output) on SM.02/H board is
not the relay output, which might not drive the DC door machine. In this case, the output points of JP7, JP8,
JP8 of SM.09IO/B board should be used to realize it.
6.3 Car controller panel SM.02/G introduction
6.3.1 Car controller panel SM02/G outside view and installation
dimension
Fig 6.5 car controller outside view
Keyhole
