STEP AS380 Series User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 7 Parameter Table of Integrated Drive Controller
163
Chapter 7 Parameter Table of Integrated Drive
Controller
7.1 F Parameter List
Table 7.1 F Parameter List
No.
Name
Factory
Setup
Scope
Unit
Remarks
F00
Accelerating slope
0.550
0.200～1.500
m/s
2
F01
Decelerating slope
0.550
0.200～1.500
m/s
2
F02
S curve T0 (initial S angle time
T0)
1.300
0.300～3.000
s
F03
S curve T1 (S angle T1 at end of
acceleration)
1.100
0.300～3.000
s
F04
S curve T2 (S angle time T2 at the
beginning of deceleration)
1.100
0.300～3.000
s
F05
S curve T3 (S angle time T3 at the
end of deceleration)
1.300
0.300～3.000
s
F06
Nominal speed
1.750
0.100～10.000
m/s
F09
Parking floor
1
1～64
×
F10
Offset floor
0
0～64
×
F11
Floor number
18
2～64
×
F12
Inspection speed
0.250
0～0.630
m/s
F13
Creeping speed
0.060
0.010～0.150
m/s
F14
Closing delay 1 (repsonse to hall
call)
3.0
0～30.0
s
F15
Closing delay 2 (repsonse to car
call)
3.0
0～30.0
s
F16
brake delay
0.2
0～2.0
s
F17
Automatic enable signal release
time
0.6
0.2～3.0
s
F18
Fire floor
1
1～64
×
F20
Base station return delay time
0
0～65535
s
0 represents not open; other
numbers represents open and
delayed time.
F21
Leveling switch motion delay
distance (full-speed)
6
0～40
mm
F22
Single and Duplex return to base
station
1
1～64
×
F23
Group control mode
0
0～3
×
F25
Input type 1 (normal open or close
setup for X0～X15 input point)
819
0～65535
×
F26
Input type 2 (normal open or close
setup for X16～X25 input point)
2
0～65535
×
F27
Elevator car board input type
(normal open or close setup for
GX0～GX15 input point)
0
0～65535
×
F28
Car roof input type (normal open
or close setup for HX0～HX15
input point)
327
0～65535
×
