STEP AS380 Series User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 5 Operator
61
F1
F1 button
Press the button at open/close control interface to open the
door
F2
F2 button
Press the button at open/close control interface to close the
door
5.1.3 Operator handling
5.1.3.1 Menu structure
Main menu structure is as the below fig 5.2. the operation interface adopt the one level
menu structure due to the structure confinement of 7-segment and button. Press left and right
button to switch between various menu, press menu key to switch between LED function selection
and open/close door control.
Instruction
registered
Self-study
instruction
Front/rear
door allowed
Fault code
System year
System date
System time
Hoist way
parameter
Car top panel
input condition
Password
login
Process
diagnosis
Level -1 main menu
use”<””>”key to switch between
various menus
F value
setting
Control
parameter
reset
LED function
selection
Door open/close
control
MENU
key
Rear door
open allowed
Drive
parameter
reset
Floor display
Input type
Parking floor
allowed
Elevator speed
Elevator running
condition
Fault code
reset
Drive
program
version
Control
program
version
Fig 5.2 menu structure
