Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 8 Elevator Elevator Commissioning Guide
According to
inverter
parameter
Motor rated slip frequency
0:increment
al Encoder
1:SIN ／
COS Encoder
2: Endat
Encoder
Note:
Before debugging, the basic parameters above must be correctly set; the basic parameters of
the motor can be input based on nameplate; according to the actual situation of the site, please
refer to Chapter VII for the parameter setting method and detailed definition.
8.4.2 Motor Parameter Self Study
No motor parameters self study for the synchronous motor. Because AS380 series elevator
integrated drive controller adopts the most advanced and unique drive technology which can
automatically obtain Encoder phase angle data, therefore, there is no need for motor auto-tuning
of Encoder phase angle.
Note that: every time AS380 series elevator integrated drive controller is used to control
synchronous motors, it will automatically capture Encoder information at its first running
after powered on, which takes 2 seconds or so. Therefore, the given running signal at this
time is slightly later than usual. Please do consider this detail in the design for this control
system, to avoid unnecessary failure.
For the induction motor, if the on-site motor parameters are confirmed to be very accurate, in
particular if the F209 (motor rated slip frequency) parameters are ensured to be accurate, the
following self study of motor internal characteristic parameters will not be necessary. However, if
the on-site motor parameters are not accurate enough, or with the purpose of ensuring excellent
operating characteristics of the system, self study can be carried out on site regarding the motor
internal operating parameters. Specific methods are as follows:
(1) The connections between AS380 series elevator integrated drive controller and motor,
between AIO and encoder have been correctly completed;
