Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 4 The Wiring Of Elevator integrated Drive Controller
Chapter 4 Wiring of Elevator Integrated Drive
Controller
This chapter defines the wiring of elevator integrated drive controller terminals, including the
wiring of main circuit terminals, control circuit terminals and PG card terminals.
◉ Before wiring, please make sure that power supply is completely
disconnected.
Or it may cause risk of electric shock.
◉ Wiring must be performed by professional electrical personnel.
Or it may cause risk of electric shock.
◉ Earth terminal E shall be grounded reliably.
Or it may cause risk of electric shock.
◉ Please never touch the terminal with hands; never have the drive
controller output line contact the enclosure.
Or it may cause risk of electric shock.
◉ Please never connect the power supply to output terminals U, V and
W.
Or it may cause damage.
◉ Please never short the terminal ◈＋1/◈＋2 with◈－.
Or it may cause risk of explosion.
◉ Please check the voltage of AC main circuit power supply is
consistent with the rated voltage of integrated driver controller.
Or it may cause risk of fire and physical injury.
◉ Please correctly connect the braking resistor as per the wiring
diagram.
Or it may cause risk of fire.
◉ Main circuit terminal must be firmly connected with the conductor
or wire crimping terminal.
Or it may cause risk of damage.
