STEP AS380 Series User Manual

Shanghai STEP Electric Corporation
10
Chapter 2 Model And Specification
2S01P5
2S02P2
2S03P7
2T05P5
2T07P5
2T0011
2T0015
2T18P5
2T0022
4T02P2
4T03P7
4T05P5
4T07P5
4T0011
4T0015
4T0018
4T0022
4T0030
4T0037
4T0045
4T0055
4T0075
Nominal current (A)
6.0
12
18
25
33
47
60
75
80
6.2
9
13
18
27
34
41
48
65
80
97
128
165
Max. output voltage (V)
200V: single-phase / three-phase 220～240 (matching input voltage)
400V: three-phase 380/400/415/440/460V (matching input voltage)
Input Power
Number of phase, voltage
and frequency
200V: ≤3.7kW, single or three phase; >3.7kW, three phase, the range of input
voltage: 200～240V, 50/60Hz;
400V: three-phase 380/400/415/440/460V、50/60Hz
Admissible voltage
fluctuation range
-15%～+10%
Admissible frequency
fluctuation range
-5%～+5%
Basic Feature
Max. floors
2～64 for single elevator
Elevator speed
≤4.00m/s
Group control number
≤8
Communication mode
CAN bus serial communication
Functions
See 3.1 for product functions
Drive Features
Control mode
With PG card vector control
Startup moment
150% 0Hz (with PG card vector control)
Speed control range
1:1000 (with PG card vector control)
Speed control precision
±0.02% (with PG card vector control 25±10℃)
Moment limit
Yes (setup by parameters)
Moment precision
±5%
Frequency control range
0～120Hz
Frequency precision
(Temp. fluctuation)
±0.1%
Frequency setup resolution
±0.06Hz/120Hz
Output frequency resolution
(Calculate resolution)
0.01Hz
Non-load startup
compensation
When lift load is unknown, impose suitable torque to the motor according to its
operation direction to start it up smoothly and minimize the slipping and
increase comfortable sensation during start-up.
Overload capacity
Zero =150% , < 3Hz =160%, > 3Hz =200%
Brake moment
150% (external braking resistor), internal braking units
Acceleration / deceleration
time
0.01～600s
Carrier frequency
2～11kHz
Battery operation
Elevator powered by battery runs in low speed to the closest floor when power
cuts.
PG
Interface
signal
PG card output power
5V、12V, 300mA
Type of PG cards
Integrated/decoupled, push-pull, difference, SIN/COS, Endat absolute value
model
PG card signal frequency
division output
OA, OB in quadrature, frequency division factor 1～128
Control
input/output
signals
OC input control power
Insulation 24V DC
Relay output control power
Insulation 24V DC
Low voltage OC insulation
input
20 ways. Switching value. OC control signal: insulation 24VDC power input
signal.
High voltage OC insulation
input
3 ways. Switching value.
Relay output 1
4 ways. normally open contact, SPST, contact capacity: resistive, 3A 250VAC
or 3A 30VDC
Relay output 2
3 ways. normally open contact, SPST, contact capacity: resistive, 6A 250VAC
CAN communication
interface
3 ways (parallel connection or group control, lift car and outcall
communication, community monitor)
Analog signal input
1 way single end or difference input, input voltage range: -10V～+10V,
precision 0.1%
Protection
Functions
Motor overload protection
Use parameters to set up motor protection curve
Transducer overload
< 3Hz = 160%, 5 sec, > 3Hz=185%, 10 sec.
