Shanghai STEP Electric Corporation
Chapter 7 Parameter Table of Integrated Drive Controller
the value from 49
th
floor to 64
th
floor. The lowest floor corresponded to floor 49
th
.
The highest floor corresponded to 64
th
floor. When the bit is set as 1, the
corresponding floor will be non-service floor during the switch validity. The
instructions and call signal from the floor can not be registered. The parameters
are under the control of a switch.
The parameters will be invalid when the switch deactivated. If setting the
parameters in group control or parallel connection, the floor sequence must be in
conformity with that of the whole group.
○ detailed setting method. Please take reference to the setting method of
F50-F52，F191.
F141—— delay release time of main contactor. The time delay range from the elimination of
running signal to main contactor release while the elevator stopped. The default is
0.5s.
F145—— busbar voltage gain. If it is found during the inspection that there is error between the
busbar voltage in display and that in actual inspection, set the parameter F145 to make
the above two data consistent. The default is 100%, which mean no adjustment.
F146—— position deviation distance. Do inspection on the deviation of leveling position when
stop the elevator. The parameter represents the allowed deviation distance.
F147—— contact inspection protection mode. 0: self-protection against fault after detecting the
contacts adhesion failure. Power cutoff or inspection reset is required. 1: stop the
elevator when detecting contact adhesion and keep running after the troubleshooting.
F152—— the delay time of auto shutdown of in-car lighting and fan. The system will
automatically shut down the in-car lighting and fan when idle time of elevator in
automatic mode reach the value set by the parameter. The default value is 3 minutes.
F153—— high-voltage input detection with or without hall door lock
1: high-voltage input detection with hall door lock.
0: high-voltage input detection without hall door lock.
The default value is 1.
F156—— detection on existence of door lock relay. 1: yes, 0: no
F160—— activation/deactivation of manually clearing away error instruction .
1: activation, 2: deactivation. When such function is activated, the wrong instruction
signal can be cleared away by pressing the button twice once the wrong instruction
signal is registered.
F161—— activation/deactivation of time slot floor blockade
1: activation, 0: deactivation.
F163—— the elevator continue to run or stop after homing while the signal or parallel backup
power supply is running. 0: the elevator stops after homing while backup power
supply is running.1: the elevator continues to run after homing while the backup
power supply is running.
F164—— load-weighing instrument type, the acquisition method of weighing signal and
compensation signal. The following table gives a list of corresponding load-weighing
instrument type, the acquisition method of different weighing signal and
compensation signal with difference F164 parameter.
