Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 8 Elevator Elevator Commissioning Guide
207
and then force the safety loop relay not to release by any means. The system should be protected
and not reset automatically;
4) Door lock loop relay adhesion protection (This function may not be tested if no door lock loop
relay)
Testing requirements: Under door-open circumstances, force the door lock loop relay not to
release by any means. The system should be protected and not reset automatically;
5) Brake contactor adhesion protection
Testing requirements: Under stop circumstances, force the brake contactor not to release by
any means. The system should be protected and not reset automatically;
6) Output contactor normal adhesion protection
Testing requirements: Under stop circumstances, force the brake contactor not to release by
any means. The system should be protected and not reset automatically;
7) Skid protection function
Testing requirements: Move the elevator Inspection to the middle floor, remove the leveling
sensor lines from the control cabinet wiring terminal (assuming leveling floor signal is normal.
open), switch to normal, the elevator goes leveling at low speed, the system protected within 45
seconds and will not reset automatically;
8) Split-level protection
Testing requirements: (1) Move the elevator Inspected to the leveling position of middle floor,
and switch to Inspection or emergency power operation. If the slow down switch is normal closed
contact, disconnect the JP8.5 wiring at the upper single deceleration switch input on the
motherboard; but if it is norm. Open contact, short JP8.5 and JP10.3 (input COM terminal). And
thus create an intentional split-level fault, and then the system will display the top floor data. Then,
change the JP8.5 wiring at the upper single deceleration switch input back to normal, and switch
the elevator to normal state, register the bottom instructions, elevator express car goes down, make
sure the elevator can decelerate and level normally to the bottom floor and does not sink to the
bottom; (2) Move the elevator Inspected to the middle floor, and switch to Inspection or
emergency power operation. If the slow down switch is normal closed contact, disconnect the
JP8.6 wiring at the lower single deceleration switch input on the motherboard; but if it is norm.
open contact, short JP8.6 and JP10.3 (input COM terminal). And thus create an intentional
split-level fault, and then the system will display the bottom floor data. Then, change the JP8.6
wiring at the lower single deceleration switch input back to normal, and switch the elevator to
normal state, register the top instructions, elevator express car goes up, make sure the elevator can
decelerate and level normally to the top floor and does not rush to the top.
9) Overload function
Testing requirements; elevator overload switching, check the elevator should not be closed, the
buzzer sounds inside the car, and the overload indicator light on.
1 Elevator function testing
(1) automatic running
Testing requirement: register several instructions in the car and confirm: elevator can
normally close the door automatically, start, run at high speed, and automatically
decelerate at the nearest registered landing, stop and cancel registration (the instruction
canceled is in consistent with the landing the elevator stop) and open door.
