Shanghai STEP Electric Corporation
Chapter 8 Elevator Elevator Commissioning Guide
Register several upper or down hall call signals, confirm: elevator can automatically
close the door, start, accelerate, run, cut, decelerate, stop, cancel and open.
(2) attendant running
Testing requirement: turn the in-car switch to attendant status, and register several
instructions. Keep pressing door-closing button to close the elevator door (if user release
the door open/close button before door closing, the elevator will immediately turn from
door-closing motion into door-opening motion until the door completely open).
Automatically start after door close, run at high speed, and auto decelerate at nearest
registered landing, stop , correctly cancel instruction and auto open door. Register
several upper and down hall call signals ,keep pressing door-closing button until elevator
close door ( if use release the door open/close button before door closing, the elevator
will immediately turn from door-closing motion into door-opening motion until the door
completely open), auto start after door closed, run at high speed, and normally cut,
decelerate, cancel and open.
(3) independent running
testing requirement: turn the in-car switch to individual status, make sure no floor
showed on hall display board
（
or display floor No with words like ― out of service―
the call button does not work, register instruction in car, and keep pressing door closing
button until elevator door closed,( if user release the door button before door closed, the
elevator will immediately turn from door-closing motion into door-opening motion until
door complete open). Auto start after door closed, run at high speed, and auto decelerate
at nearest floor with instruction registered, and stop, cancel and auto open the door.
(4) Return at fire
Testing requirement: when elevator park at the certain floor other than firefighting return
base station （appointed by F18）, turn the switch of base station return at fire into On
position, all registered instructions and call signals will be completely canceled without
any more registration allowed. The elevator will close door immediately, and return to
firefighting base station in express car mode and the elevator open door and be out of
service after auto door opening. When elevator run in the opposite direction of
firefighting base station in express car mode, turn the base station firefighting return
switch into On position. All registered instructions and call signals will be completely
canceled without any more registration allowed. The elevator will park at nearest station
without door open, and return to base station in express car mode and the elevator open
door and be out of service after auto door opening. When elevator run in the direction of
firefighting base station in express car mode, turn the base station firefighting return
switch into On position. All registered instructions and call signals will be completely
canceled without any more registration allowed. The elevator will bypass to the base
station with stop, and elevator open door and be out of service after auto door opening
until firefighting return switch reset and elevator return to normal running status.
(5) firemen operation (only firefighting ladder)
Testing requirement: turn the elevator firemen operation switch into on position, elevator
will immediately enter into emergency return for firefighting base station (appointed by
F18) status. The whole process and motion is complete same as that of the above fire
return. After elevator return to the firefighting base station, stop and open the door,
