Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 8 Elevator Elevator Commissioning Guide
elevator enter into firemen operation status. At this time, there is no auto door opening or
closing motion automatically. When doing door closing operation in door complete
opening status, keep pressing door-closing button or instruction button, and elevator will
turn form door closing motion to door opening motion until door completely open. If
closing door by keep pressing instruction button, the corresponding instruction signals
will be registered after door closed. Press the instruction button for other floor in door
closing status, the instruction signal will also be registered. After instruction signal
registered, the elevator will immediately start automatically, run at high speed, and slow
down at the registered floor and stop. Car stop enable all registered instruction signals to
be removed. When car stop with door closed, keep pressing door-opening button to
maintain door open until the door open in place. Once release the door-opening button in
the process of door opening, the elevator will immediately change from door opening
motion into door closing motion until the door is completely closed. The call button will
always out of function in the fireman operation mode. Only when the elevator park at the
firefighting base station, elevator doors open in place and firefighter switch reset, the
elevator can return to normal running status.
(6) group control in duplex (only for elevator in duplex or group control)
Testing requirement: register several hall call signals and confirm the control system will
allocate most recent or convenient elevator to respond registered call signals. When one
elevator responded a call, the same call signals of all elevators in the same floor will be
canceled at the same time. It is not allowed to have two or more than two elevator to
respond the same call signal, to ensure the down call signals of top floor registered
effectively, and enable the nearest or most convenient elevator to respond. When each
elevator in the group has inconsistent service floor, do the following test for the floors
that only some of elevators can park: move the elevator from it original floor to the floor
a little bit far, and move the elevators that can not park at the floor to park at the near
floor. When register call signal for the floor, ensure a nearest elevator in those for that
floor to respond immediately. If base station return function and standby elevator
disperse function is available, make sure that the parking floor location is conform to the
result of required return base station and elevator standby disperse
(7) elevator lock function
Testing requirement: suppose that elevator stop at the floor outside of elevator lock base
station or is running, turn the elevator lock key at base station to the position of elevator
lock. The elevator can erase all registered call signal and will not register any new call
signal. And landing display of the floor extinguishes or shows the words ―out of service‖.
The elevator will continue to respond instruction (before arrive base station, continue to
accept new instruction registration signal). After finish response of instruction signal,
automatically return to base station, stop car and open door, cut off in-car lighting and fan
power after door complete its opening, delay 10seconds and then close the door. The
elevator then is out of service.
