Stihl MS 441 User Manual

105MS 441, MS 441 C
– Fit end cover on carburetor
housing from below so that the
gasket and pump diaphragm
remain secured in position on the
end cover.
– Move the end cover (1) slightly
until the pegs in the end cover
engage the holes in the
carburetor housing.
– Check that diaphragm and
gasket are correctly seated.
219RA231 TG
1
: Fit and tighten screw.
– Remove carburetor, b 14.3.
The screws (arrows) must not be
removed. They have been set and
sealed by the manufacturer. The
choke or throttle shaft must be
removed to replace the
corresponding leg spring.
219RA232 TG
If the choke shaft moves stiffly or if
the choke shutter does not open or
close properly:
Remove choke shaft and clean the
shaft and shaft guides with a little
commercially available solvent-
based degreasant not containing
any chlorinated or halogenated
hydrocarbons.
– Turn choke shaft until choke
shutter is closed.
: Take out screw (arrow) in choke
shutter.
62-74
219RA233 TG
: Turn choke shaft slightly and take
out choke shutter (1).
219RA234 TG
1
: Take out screw (arrow).
– Remove lever (1).
219RA235 TG
1
: Push choke shaft (1) towards
connector.
– Remove lock washer (arrow).
219RA234 TG
1
14.4.6 Choke shaft/
choke shutter

Stihl MS 441 Specifications

General

Displacement	70.7 cc
Weight	6.6 kg
Fuel Capacity	0.78 L
Chain Oil Capacity	0.36 l
Oil Capacity	0.36 l
Oil tank volume	0.36 l
Chain pitch	3/8"
