Stihl MS 441

123MS 441, MS 441 C
: Push fuel hose (1) through the
opening (arrow).
– Use STIHL Press Fluid for easier
insertion, b 17.
219RA552 TG
1
– Press fuel hose (1) in until rubber
lip (arrow) encloses the opening
completely.
219RA553 TG
1
Machines with QuickStop Super
– Guide fuel hose (1) under brake
cable (2) and push it onto the
elbow connector (arrow).
– Reassemble all other parts in the
reverse sequence.
219RA096 TG
1
2
– Open filler cap.
: Prise out nipple inside tank
(arrow).
219RA555 TG
– Examine filler cap, rope and
O-ring, replace if necessary.
: Press nipple into mount (arrow)
inside tank.
– Close fuel filler cap.
219RA556 TG
– Perform leakage test.
14.8.3 Fuel filler cap
