Stihl MS 441 User Manual

19MS 441, MS 441 C
Wear work gloves to protect your
hands from injury.
: Unscrew hex nuts (1).
: Remove chain sprocket
cover (2).
VA
138RA002
1
2
3
: Remove bar (3) and chain.
– Reassemble in the reverse
sequence.
– Troubleshooting chart, b 4.1.
– Remove chain sprocket cover,
bar and chain, b 5.
– Remove clutch drum, b 6.1.
– Remove carburetor box cover,
b 14.1.
: Pull boot (1) off spark plug.
1
2
19RA015 TG
: Unscrew spark plug (1).
2
19RA016 TG
1
: Push locking strip (1)
0000 893 5903 into the spark
plug hole so that "OBEN-TOP"
faces up.
1
2
19RA017 TG
: Unscrew clutch (1).
The clutch has a left-hand thread.
1
2
19RA018 TG
Disassembling the clutch
: Use hook (2) 5910 890 2800 to
remove the clutch springs (1).
2
19RA019 TG
2
1
5. Saw chain/ chain guide 6. Clutch

Stihl MS 441 Specifications

General

Displacement	70.7 cc
Weight	6.6 kg
Fuel Capacity	0.78 L
Chain Oil Capacity	0.36 l
Oil Capacity	0.36 l
Oil tank volume	0.36 l
Chain pitch	3/8"
