20 MS 441, MS 441 C
– Pull clutch shoes off the carrier.
: Pull retainers (1) off the clutch
shoes.
1
2
19RA020 TG
– Clean all parts.
– Replace any damaged parts.
2
19RA021 TG
: Slip retainers (1) onto the clutch
shoes.
1
2
19RA022 TG
: Fit clutch shoes (2) over the
arms (1).
219RA023 TG
21
: Clamp the clutch in a vice
(arrow).
2
19RA024 TG
Attach the springs to the side with
the raised hexagon (arrow).
: Attach one end of each spring (1)
to the clutch shoes.
1
2
2
19RA025 TG
: Use hook (2) 5910 890 2800
to attach the other end of the
spring and press it firmly into the
clutch shoe.
: Check the clutch: all springs
(arrows) must be attached
completely.
2
19RA026 TG
– Washer (1) must be fitted.
It has been fitted correctly when
"TOP" (arrow) faces outwards.
TOP
1
2
19RA027 TG

Stihl MS 441 Specifications

General

Displacement	70.7 cc
Weight	6.6 kg
Fuel Capacity	0.78 L
Chain Oil Capacity	0.36 l
Oil Capacity	0.36 l
Oil tank volume	0.36 l
Chain pitch	3/8"
