96 MS 441, MS 441 C
Standard filter (green) with wire
mesh for normal operating
conditions and use in winter.
– Examine air filter, replace if
necessary.
– Tap filter clean or blow through
219RA485 TG
compressed air from the inside
outwards.
– To remove stubborn dirt, wash
the filter in STIHL all-purpose
detergent or a clean, non-
flammable cleaning liquid (e.g.
lukewarm soapy water) and then
dry it.
Do not oil the filter.
– Reassemble in the reverse
sequence.
– Remove air filter, b 14.1.
: Take out nuts (arrows).
– Remove baffle (1).
219RA486 TG
1
– Examine baffle, replace if
necessary.
– Reassemble in the reverse
sequence.
– Tightening torques, b 3.5.
219RA487 TG
– Test air filter, b 14.1.
– Remove baffle, b 14.1.1.
– Remove spacer flange,
b 14.2.
: Disconnect lead (1) on machines
with handle heating (arrows).
219RA488 TG
1
: Take out nuts (arrows).
– Remove filter base (1).
219RA490 TG
1
14.1.1 Baffle 14.1.2 Filter base

Stihl MS 441 Specifications

General

Displacement	70.7 cc
Weight	6.6 kg
Fuel Capacity	0.78 L
Chain Oil Capacity	0.36 l
Oil Capacity	0.36 l
Oil tank volume	0.36 l
Chain pitch	3/8"
