21MS 441, MS 441 C
: Position clutch on crankshaft stub
so that the raised hexagon
(arrow) faces outwards.
2
19RA028 TG
TOP
: Screw clutch (1) onto the
crankshaft stub with the hexagon
(arrow) and tighten it down – left-
hand thread.
– Tightening torques, b 3.5.
– Pull locking strip out of the
1
2
19RA029 TG
cylinder.
– Reassemble all other parts in the
reverse sequence.
– Remove chain sprocket cover,
bar and chain, b 5.
: Pull hand guard (1) towards the
front handle.
1
2
19RA030 TG
: Remove circlip (1).
: Remove washer (2).
2
19RA031 TG
2
1
: Remove rim sprocket (1).
2
19RA032 TG
1
: Remove clutch drum (1).
1
2
19RA033 TG
Machines with QuickStop Super
Disengage the brake before
removing the clutch drum.
: Press and hold the trigger
interlock (1).
1
2
19RA034 TG
– Remove clutch drum.
6.1 Clutch drum

Stihl MS 441 Specifications

General

Displacement	70.7 cc
Weight	6.6 kg
Fuel Capacity	0.78 L
Chain Oil Capacity	0.36 l
Oil Capacity	0.36 l
Oil tank volume	0.36 l
Chain pitch	3/8"
