44 MS 441, MS 441 C
– Remove carburetor box cover,
b 14.1.
: Pull boot off spark plug (1).
1
2
19RA015 TG
: Unscrew slotted nut (arrow).
: Lift shroud (1) off decompression
valve (2).
219RA299 TG
2
1
: Pull off stop buffer (1) and
examine it, fit a new stop buffer if
necessary.
219RA278 TG
1
: Pull off rubber grommet (3) and
remove slotted nut (1).
: Examine slotted nut (1),
insulating element (2) and rubber
grommet (3), replace if
necessary.
219RA288 TG
3
2
1
– Slide slotted nut (1) with
insulating element into hole.
: Fit rubber grommet (2) until it
engages the groove in the slotted
screw.
219RA290 TG
21
: Ease out rubber grommet (1) and
examine it, fit a new grommet if
necessary.
219RA298 TG
1
: Press rubber grommet (1) in until
the groove (arrow) engages the
rebate (2) in the housing.
– Use STIHL Press Fluid for easier
insertion, b 17.
219RA290 TG
1
2
– Remove filter base, b 14.1.2.
: Push out rubber grommet (1) and
examine it, replace if necessary.
219RA360 TG
1
: Pull grommet (1) in until the lug
(arrow) has been pulled in
completely.
– Use STIHL Press Fluid for easier
insertion, b 17.
219RA361 TG
1
8.4 Shroud, removal and
installation

Stihl MS 441 Specifications

General

Displacement	70.7 cc
Weight	6.6 kg
Fuel Capacity	0.78 L
Chain Oil Capacity	0.36 l
Oil Capacity	0.36 l
Oil tank volume	0.36 l
Chain pitch	3/8"
