122 MS 441, MS 441 C
– Remove carburetor housing,
b 14.6.2.
: Push fuel hose (1) out.
219RA544 TG
1
: Pull off elbow connector (1).
– Remove pick-up body, b 14.8.1.
219RA545 TG
1
: Ease out fuel hose (1).
– Pull fuel hose out from inside
tank.
219RA546 TG
1
: Examine fuel hoses and replace
if necessary.
219RA547 TG
: Push fuel hose (1) into opening
(arrow) in fuel tank.
219RA548 TG
1
: Fit flange (1) and press it into the
fixture (arrow) on the housing
until it rests against the housing.
219RA549 TG
1
: Push elbow connector (1) into
fuel hose (arrow).
219RA550 TG
1
: Pull fuel intake hose (1) out of
fuel tank with assembly hook
5910 893 8800.
Do not over-extend the fuel hose.
– Install pick-up body, b 14.8.1.
219RA551 TG
1
14.8.2 Fuel hoses

Stihl MS 441 Specifications

General

Displacement	70.7 cc
Weight	6.6 kg
Fuel Capacity	0.78 L
Chain Oil Capacity	0.36 l
Oil Capacity	0.36 l
Oil tank volume	0.36 l
Chain pitch	3/8"
