98 MS 441, MS 441 C
– Remove air filter, b 14.1.
: Take out screws (arrows).
– Turn switch shaft to position "#"1
and remove spacer flange (1).
219RA495 TG
1
– Examine spacer flange, replace if
necessary.
The new spacer flange is supplied
complete with rubber buffers and
clamps.
219RA496 TG
: Drive out rubber buffers (arrows)
and examine them, replace if
necessary.
219RA497 TG
: Press rubber buffer (1) into hole
(arrow) until it encloses the hole
completely.
– Use STIHL Press Fluid for easier
insertion, b 17.
219RA498 TG
1
: Press tab (arrow) downwards.
– Turn clamps downwards.
219RA499 TG
: Slide clamps (1) up and out of the
mount.
219RA500 TG
1
– Examine clamps, replace if
necessary.
– Install clamps in reverse
sequence, taking care to ensure
that the tab engages.
Ensure that the clamps are open.
: Slide spacer flange (1) into
position over the switch shaft
(arrow).
– The bearing guides must engage
the buffers in the filter base.
219RA489 TG
1
– Insert screws and tighten them
down.
– Reassemble all other parts in the
reverse sequence.
– Tightening torques, b 3.5.
14.2 Spacer flange

Stihl MS 441 Specifications

General

Displacement	70.7 cc
Weight	6.6 kg
Fuel Capacity	0.78 L
Chain Oil Capacity	0.36 l
Oil Capacity	0.36 l
Oil tank volume	0.36 l
Chain pitch	3/8"
