Stihl MS 441

108 MS 441, MS 441 C
: Position tensioned leg spring on
shoulder (arrow) of carburetor
housing.
219RA250 TG
: Install circlip (1).
219RA251 TG
1
: Slide throttle cable retainer (1)
onto the throttle shaft with the
shoulder (arrow) first.
219RA252 TG
1
– Position lever (1) so that the word
"TOP" is at the front.
: Lever (1) must be fitted behind
lever (2); then push it into the
groove (arrow) of the throttle
cable retainer and onto the
mating lug of the throttle shaft.
219RA253 TG
2
1
: Insert and tighten screw (arrow).
– Turn throttle shaft to full throttle
position.
219RA275 TG
: Slide throttle shutter (1) into the
slit in the throttle shaft with the
recess (arrow) at the front and
the hole (2) on the left.
219RA254 TG
2
1
