Strasbaugh Installation
Version 1.2 - April 18, 1996 2 - 5
LOCATION
The location for the machine requires a flat stable surface (e.g.
concrete slab) with a minimum of three feet of clearance around
the perimeter of the machine. It should be as close as possible
to required connections and allow sufficient space for operator
movement.
LEVELING
Using the work chuck as a reference, the machine should be
level to within .005" per foot. Four leveling feet are provided
under the main machine cabinet. Turn the jack screws to level
the machine. Once level, all locknuts should be tightened to
maintain position.
