Operation
Charging the battery (option) (Continued)
Notes
• The batteries will have a full charge within approximately 10 hours.
• Three LEDs on the head end control panel may illuminate with products that have the Zoom option ( Zoom
motorized drive panel (option)on page 59), even in power save mode. The battery power switch LED on the lower
left corner of the head end, will illuminate when the unit is in power save mode.
Activating the CPR release
CAUTION
Always make sure that all persons and equipment are away from the area below and around the Fowler before you
activate the CPR release. The CPR release is for emergency use only.
When you raise the Fowler and need quick access to the patient, you can position the product to 0° by activating the
CPR release.
You can find the two CPR release levers at the head end section on both the left and right sides of the Fowler (A)
(Figure 9 on page 23).
To activate the CPR release:
1. Grasp and squeeze the lever on either side of the Fowler.
2. Guide the Fowler to the flat position.
A
Figure 9: Activating the CPR release

Stryker S3 Specifications

General

Weight Capacity	500 lbs (227 kg)
Maximum Patient Weight	500 lbs (227 kg)
Bed Frame Material	Steel
Type	Hospital Bed
Bed Width	35 inches (89 cm)
Caster Size	5 inches (12.7 cm)
Electrical Requirements	120 VAC, 60 Hz
Width	35 inches (89 cm)
Power Requirements	120 VAC, 60 Hz
Power Backup	Battery backup available
Accessories	IV pole
Siderails	Yes
