26 3006-209-001 REV B www.stryker.com
Operation
Installing the patient restraint strap tie-ins (Continued)
There are eight patient restraint strap tie-in locations on the litter assembly for installing patient restraint straps. Two are
located on the Fowler section, two are located on the seat section, and four are located on the foot section (Figure 13
on page 26).
Figure 13: Restraint strap tie-in locations
Raising the siderails
WARNING
• Always set the siderail position to make sure that a patient is safely in the product.
• Always lock the operator control panel and patient control panel when the patient is unattended.
• Always keep the siderails outside of the oxygen tent.
Note: Do not use siderails as a patient restraint device.
When raising the siderails, listen for the click that indicates that the siderail has locked into position. Pull on the siderail
to make sure that it is locked.
To raise the siderail to its highest position, grasp the release handle and rotate the siderail toward the head end of the
product (Figure 14 on page 27).
Note: The siderail does not lock into the intermediate position when you raise the siderail.
