16 3006-209-001 REV B www.stryker.com
Setup
WARNING
Always plug the product directly into a grounded, hospital grade wall outlet. You can only achieve grounding reliability
when you use a hospital grade wall outlet. This product is equipped with a hospital-grade plug for protection against
electric shock hazard.
Before you place the product into service, make sure these components are working properly:
1. Plug the product into a grounded, hospital grade wall outlet and make sure that the power button LED light at the
foot end of the product comes on.
2. Make sure that the siderails raise, lower, lock in the up position, lock in the intermediate position when lowered and
store smoothly.
3. Make sure that all four casters lock when the brake is applied.
Note: Make sure that the Brake LED located on the outside of the head end siderails (Operator control panel
(outside siderail) on page 34) and on the footboard control panel (Figure 27 on page 43) blink when the brakes are
released.
4. Raise the Fowler (head of bed) up to approximately 60°. Squeeze the CPR release handle and make sure that the
back will drop with minimal effort.
5. Perform each function on the footboard control panel to make sure that each function is working.
6. Perform each function on both head end siderails to make sure that each function is working.
7. Activate the motion stop system to make sure that it is working. Press the Bed height down button to lower the litter.
As the litter lowers, push up on the motion interrupt pan under the litter and make sure that the downward motion
stops. Release the pan and allow the downward motion to continue.
Note: The product’s upward motion or other functions are not disrupted by the motion stop system
Equipping the optional nurse call communication
WARNING
Always use a Stryker supplied interface cable. Use of any other cable may cause the bed to function improperly, which
may result in patient or user injury.
If your product is equipped with the optional nurse call communication, follow the setup instructions below before putting
the product into service.
1. Plug the interface cable into the 37-pin connector in the litter frame at the head end of the product (B) (Figure 3 on
page 17) and into the applicable connection (patient station, head wall, or docker station).
Note: Only connect the 37-pin connector to the head wall output configuration (B) (Figure 3 on page 17) or product
Communications Tester (sold separately).
2. Test the interface cable to verify connectivity.
3. Plug the power cord into the wall outlet.
4. Push in the pendant port switch and turn the switch to the on position (90° clockwise) (A) (Figure 3 on page 17).
5. Press the Nurse call button (see Operator control panel (outside siderail) on page 34) to verify the connection
between the product’s nurse call signal and the hospital’s nurse call system.
Note: A 9V battery, located in the head end of the product, powers the nurse call signal. If the product is unplugged
from a wall outlet while the nurse call pendant port switch is set to the on position, the charge of the 9V battery will
begin to drain.
