Stryker S3 User Manual

www.stryker.com 3006-209-001 REV B 55
Operation
Setting the iBed Awareness nurse call alarm
S3 sends a signal through the nurse call system when a parameter condition is compromised.
To set up an iBed Awareness alarm through the nurse call system:
1. Press the Menu button (A). See Menu display on page 47.
2. Scroll to Advanced options.
3. Press the Enter button (F). See Menu display on page 47.
4. Scroll to Status to nurse call.
5. Press the Enter button (F). See Menu display on page 47.
6. Select On.
7. Press the Enter button (F). See Menu display on page 47.
Note:
A confirmation notification indicates that you set the alarm tone.
iBed Awareness (option)
C
A
D F
E
G
B
Note: For a description of the menu functions, see Menu display on page 47.
A iBed
Arms/disarms iBed Awareness
B Menu Accesses menu functions
C
Display Displays menu functions
D
Up arrow Scroll up through menu functions
E Down arrow
Scroll down through menu functions
F Exit
Exits from menu functions or cancels
operation
G Enter
Selects menu functions or saves
operation

Stryker S3 Specifications

General

Weight Capacity	500 lbs (227 kg)
Maximum Patient Weight	500 lbs (227 kg)
Bed Frame Material	Steel
Type	Hospital Bed
Bed Width	35 inches (89 cm)
Caster Size	5 inches (12.7 cm)
Electrical Requirements	120 VAC, 60 Hz
Width	35 inches (89 cm)
Power Requirements	120 VAC, 60 Hz
Power Backup	Battery backup available
Accessories	IV pole
Siderails	Yes
