Stryker S3 User Manual

www.stryker.com 3006-209-001 REV B 61
Operation
Motion and communication pendant (option)
A
C
D
G
H
B
E
F
I
J
K L
A
TV Turns the TV on or off
B Nurse call Activates nurse call
C
Volume up
Increases the volume
D Volume down Decreases the volume
E
TV Channel up Changes the TV channel up
F
TV Channel down
Changes the TV channel down
G
Fowler up
Raises the Fowler
H Fowler down Lowers the Fowler
I
Gatch up
Raises the gatch
J
Gatch down
Lowers the gatch
K
Room light Turns the room light on or off
L Product overhead light Turns the product overhead light on or off

Stryker S3 Specifications

General

Weight Capacity	500 lbs (227 kg)
Maximum Patient Weight	500 lbs (227 kg)
Bed Frame Material	Steel
Type	Hospital Bed
Bed Width	35 inches (89 cm)
Caster Size	5 inches (12.7 cm)
Electrical Requirements	120 VAC, 60 Hz
Width	35 inches (89 cm)
Power Requirements	120 VAC, 60 Hz
Power Backup	Battery backup available
Accessories	IV pole
Siderails	Yes
