44 3006-209-001 REV B www.stryker.com
Operation
Footboard LED indicators (Continued)
Indicator LED illuminates amber
G
Siderail (optional iBed Awareness)
iBed Awareness system is on. The LED will blink
amber when siderail state has changed.
H Power
Green when bed has power.
Footboard control panel - Scale
A Scale
Weighs the patient
B Zero Sets the scale to zero
Note: The Bed Zero LED indicator illuminates when you set the scale to zero (Figure 27 on page 43).
Weighing a patient
WARNING
• Do not use the scale system reading as a reference for medical treatment.
• The scale system assists only in the monitoring of the patient’s weight variation.
• Do not set the scale to zero or weigh the patient when a support surface therapy is active. Motion from the support
surface functions may adversely affect the scale system performance.
• Power save mode activates after one hour on battery power with no motion release switch activation. Bed exit,
scale, and product motion stops operating when the product enters the power save mode.
CAUTION
Always raise the siderails when the litter is in its full down position. This prevents the scale system from weighing a
patient inaccurately.
