5-6 Sun Fire X4150 Server Service Manual • November 2009
Note – Make a note of the drive locations before removing them from the system.
You will need to install the drives in the correct locations when reassembling the
system.
3. If you are servicing the drives backplane, remove the DVD/USB module.
See Section 3.5, “Servicing the DVD/USB Module” on page 3-19.
4. Remove the fan modules.
See Section 3.3.4, “Removing a Fan Module” on page 3-11.
5. Remove the No. 2 Phillips screws securing the drives cage to the chassis
(
FIGURE 5-3 [1] and [2]).
Two screws secure the disk cage to each side of the chassis.
6. Slide the drives cage forward to disengage the backplane from the paddle cards
(
FIGURE 5-3 [3]).
7. Lift the drives cage up and disconnect the drive data cables (
FIGURE 5-3 [4]).
Press the connector release button to release the cable.
8. Set the drives cage on an antistatic mat.
