Chapter 1 Sun Fire X4150 Server Overview 1-5
1.2.2 Dimensions
The 1U chassis form factor dimensions are listed in TABLE 1-3.
1.2.3 System Cables
The Sun Fire X4150 Server internal cables are listed in TABLE 1-4.
See Section 5.7, “Servicing Cables” on page 5-18 for instructions on replacing cables.
TABLE 1-3 Sun Fire X4150 Server Dimensions
Dimension Sun Fire X4150 Server
Height 44 mm/1.73 inches
Width 425.5 mm/16.75 inches
Depth 711.2 mm/28.0 inches
Weight Minimum: 13.9 kg/30.6 lbs.
Maximum: 18.4 kg/40.6 lbs.
TABLE 1-4 Sun Fire X4150 Server Cables
Cable Connects...
Top cover interlock To the power distribution board
Ribbon cable Between the power distribution board and the motherboard
Drives data cables (2) Between the motherboard (or optional HBA PCI-Express Card)
and the drives backplane
