Chapter 5 Servicing Infrastructure Boards and Components 5-25
b. Route the cable down in front of fan board 0 to prevent it from blocking the
air stream.
Lay it through the opening in the midwall opposite the other disk backplane
connector.
c. Plug the connector into the connector on the motherboard.
2. Install the disk 4-5 cable.
a. Plug the backplane connector into the drives backplane.
b. Route the cable over the Disk 0-3 cable in the same channel through the
midwall.
c. Plug the connectors into the SATA 0-3 three connectors on the motherboard.
■ The connector labeled 4 plugs into the connector labeled SATA4.
■ The connector labeled 5 plugs into the connector labeled SATA5.
■ The unlabeled rectangular connector plugs into the connector directly behind
the two SATA connections.
Note – Note the key direction before plugging in this connector.
3. Dress the cables in the cable tie downs, and then secure the cable tie downs.
4. Re-install the fans to fan board 0.
5. Return the server to operation.
a. Install the top cover.
See Section 6.1, “Installing the Top Cover” on page 6-2.
b. Install the server into the rack.
See Section 6.2, “Reinstalling the Server in the Rack” on page 6-3.
c. Reconnect the power cord (or cords) to the power supply (or supplies).
Verify that the AC Present LED is lit.
See Section 6.4, “Powering On the Server” on page 6-6.
d. Power on the server.
See Section 6.4, “Powering On the Server” on page 6-6.
