1-2 Sun Fire X4150 Server Service Manual • November 2009
Ethernet ports 4 ports, 10/100/1000 Mbps, auto-negotiating through two separate
controllers
Internal drives • SAS (up to 8) or SATA (up to 6) disk drives (hard drive or SSD)
• Up to 8 SFF SAS 2.5-inch form factor drives. Support for
hardware-embedded RAID 0 (striping) and RAID 1 (mirroring)
• Up to 4 32GB SSDs
• Optional RAID Levels 0, 1, IE, 5, 5EE, 6, 10, 50, 60 with SAS drives
Removable
media
1 slimline DVD drive, supporting CD-R/W, CD+R/W, DVD-R/W,
DVD+R/W
USB ports 5 USB 2.0 ports: 2 in front, 2 in rear, plus 1 internal USB port
Service ports • 1 RJ-45 serial management port (SER MGT)
(default connection to access service processor)
• 1 10-MB network management port (NET MGT)
(to access service processor)
• HD-15 VGA video port
Cooling • 7 hot-swappable system fan modules (2 fans per module)
• An air baffle facilitates processor/memory airflow
PCI interfaces 3 standard, low profile, half length, PCIe slots on three riser boards
(x8 electrical/x16 mechanical)
Power • AC power: 100–120/200–240 V AC, 12/6 A, 50–60 Hz
• 1 or 2 hot-swappable 650W power supply units (PSUs) to provide N+N
redundancy, with energy efficient design
TABLE 1-1 Sun Fire X4150 Server System Features (Continued)
Feature Description (Sun Fire X4150 Server)
