Chapter 1 Sun Fire X4150 Server Overview 1-9
FIGURE 1-4 Power Distribution/Fan Module Components (Sun Fire X4150 Server)
Figure Leg end
1 Power Distribution Board/Bus Bar Assembly 4 Air Baffle
2 Paddle Card 5 Fan Modules
3 Power Supplies 6 Fan Boards
