Chapter 2 Preparing to Service the System 2-7
Caution – If necessary, use two people to dismount and carry the chassis.
To remove a server from the rack:
1. Disconnect all the cables and power cords from the server.
2. Extend the server to the maintenance position.
See Section 2.5, “Extending the Server to the Maintenance Position” on page 2-5.
3. Press the metal lever that is located on the inner side of the rail to disconnect
the cable management arm (CMA) from the rail assembly (
FIGURE 2-4).
The CMA is still attached to the cabinet, but the server chassis is now
disconnected from the CMA.
FIGURE 2-4 Metal Lever and Cable Management Arm
