3-6 Sun Fire X4150 Server Service Manual • November 2009
a. Unconfigure the drive, as required. You must take the drive offline (to
prevent any applications from accessing it, and to remove the logical
software links to it) before you can safely remove it.
See one of the following HBA documents:
For Sun StorageTek: Sun StorageTek RAID Manager Software User's Guide
For LSI MegaRAID Storage Manager (MSM): x64 Server Utilities Reference
Manual
■ To cold-plug a drive: You must power off the server before you can safely
remove the drive. Do one of the procedures described in Section 2.4,
“Powering Off the Server” on page 2-3.
4. On the drive you plan to remove, push the drive release button to open the latch
([1]
FIGURE 3-3).
5. Grasp the latch [2] and pull the drive out of the drive slot [3].
Caution – The latch is not an ejector. Do not bend it too far to the right. Doing so can
damage the latch.
FIGURE 3-3 Locating the Drive Release Button and Latch
