4-26 Sun Fire X4150 Server Service Manual • November 2009
Note – Only install the FB-DIMMs in the slots (connectors) from which they were
removed. See Section 4.1.1, “FB-DIMM Guidelines” on page 4-3.
12. Install the air baffle.
See “To Install the Air Baffle” on page 4-13.
13. Reinstall the PCIe cards and risers.
See “To Install a PCIe Riser” on page 4-16.
14. Return the server to operation.
a. Install the top cover.
See Section 6.1, “Installing the Top Cover” on page 6-2.
b. Install the server into the rack.
See Section 6.2, “Reinstalling the Server in the Rack” on page 6-3.
c. Reconnect the power cord (or cords) to the power supply (or supplies).
Verify that the AC Present LED is lit.
See Section 6.4, “Powering On the Server” on page 6-6.
d. Power on the server.
See Section 6.4, “Powering On the Server” on page 6-6.
