14. Implementation Dependencies
The FPRS.DU and FPRS.DL may be set pessimistically, even though the instruc-
tion that modified the floating-point register file is nullified.
14.3.5 Floating-Point Status Register (FSR) (Impdep #13, 19, 22, 23, 24)
UltraSPARC supports precise-traps and implements all three exception fields
(TEM, cexc, and aexc) conforming to IEEE Std 754-1985. The state of the FSR after
reset is documented in Table 10-1, “Machine State After Reset and in RED_state,”
on page 172.
u: Unused field, read as 0.
Note: The LD{X}FSR instruction should write zeroes to the u fields; undefined
values (read as 0) of these fields are stored by the ST{X}FSR instruction.
fcc3, fcc2, fcc1, fcc0: Four sets of 2-bit floating-point condition codes, which are
modified by the FCMP{E} (and LD{X}FSR) instructions. The FBfcc,
FMOVcc, and MOVcc instructions use one of these condition code sets to
determine conditional control transfers and conditional register moves.
Note: fcc0 is the same as the fcc in SPARC-V8.
Table 14-7 Floating-Point Status Register Format
Bits Field Use RW
<63:38> Reserved —R
<37:36> fcc3 Floating-point condition code (set 3) RW
<35:34> fcc2 Floating-point condition code (set 2) RW
<33:32> fcc1 Floating-point condition code (set 1) RW
<31:30> RD Rounding direction RW
<29:28> u Unused R
<27:23> TEM IEEE-754 trap enable mask RW
<22> NS Non-standard floating-point results R
<21:20> Reserved —R
<19:17> ver FPU version number R
<16:14> ftt Floating-point trap type RW
<13:> qne Floating-point deferred-trap queue (FQ) not empty RW
<12> u Unused R
<11:10> fcc0 Floating-point condition code (set 0) RW
<9:5> aexc Accumulated outstanding exceptions RW
<4:0> cexc Current outstanding exceptions RW
