Sun Microelectronics
78
UltraSPARC User’s Manual
• Store buffer requests. The store buffer priority is made higher than the load
buffer priority when the store buffer reaches five entries; it remains higher
until the number of entries drops to two.
• The request for the first 16 bytes of data from the I-Cache/Prefetch Unit. After
the first clock of an I-Cache request, its priority becomes higher than load and
store buffer requests.
The UDB contains:
• A read buffer that holds a model-dependent number of 64-byte lines coming
from main memory; these satisfy E-Cache read misses or noncacheable reads.
Table 7-3 shows the supported buffer depth for each UltraSPARC model.
• A model-dependent number of 64-byte buffers to hold writebacks, block
stores, and outgoing interrupt vectors. The writeback buffer(s) are in the
coherence domain; consequently, it can be used to satisfy copyback requests
from the system. Table 7-5 shows the number of Writeback buffer entries for
each UltraSPARC model. Note: Models that support more than one Writeback
buffer entry can be restricted to using only one entry.
• Eight 16-byte noncacheable store buffers.
• A 24-byte buffer to hold an incoming Interrupt Vector. (Each UDB chip
contains a 24-byte interrupt vector buffer, but only one buffer is used.)
7.3.2 UltraSPARC E-Cache and UDB Transactions
This section describes transactions occurring between UltraSPARC, the E-Cache,
and the UDB. Interconnect transactions are described in a later section. Transi-
tions in the timing diagrams show what is seen at the pins of UltraSPARC.
Cache line states are defined in Section 7.6, “Cache Coherence Protocol,” on page
94. Signals are defined in Appendix E, “Pin and Signal Descriptions.”
Table 7-4 Supported Read Buffer Depth
UltraSPARC-I UltraSPARC-II
# of Entries 13
Table 7-5 Supported Number of Writeback Buffer Entries
UltraSPARC-I UltraSPARC-II
# of Entries 12
