Handle forward, main winch down
Handle backward, main winch up
Handle leftward, main winch turn left.
Handle rightward, main winch turn right
★Press “Button 2”,the main volume motor
variable, the speed is getting faster.
★Press “Button 3” , the horn control button.
★Press “Button 4”,the upper-carriage swing
automatically.
★When the drill bar is in upper limit, press
“Button 1 +Button 2” and “Button 1-
Working switch” in the membrane key panel
is unconnected, the upper limit is cancelled.
Control engine speed and output power
a——Low idle position
b——High idle position
When the accelerator knob turns
clockwise from “a” to ”b”, the engine speed
will increase.
When the accelerator knob turns
anticlockwise from “b” to ”a”, the engine speed
will slow down.
