10-20 SERVICING INFORMATION
Grommet
Clamp
CKP sensor
Oil pressure
switch
14 N·m
1.4 kgf-m
10.0 lb-ft
Speed
sensor
Engine ground lead wire
1.5 N·m
(0.15 kgf-m, 1.0 lb-ft)
6 N·m
(0.6 kgf-m, 4.5 lb-ft)
GP switch lead wire
Clamp
Clamp
Generator
GP switch
lead wire
is made to
slacken.
GP switch
Clamp
5 N·m
(0.5 kgf-m, 3.5 lb-ft)
10 N·m
(1.0 kgf-m, 7.0 lb-ft)
Grommet
11 N·m
1.1 kgf-m
8.0 lb-ft
45˚
4.5 N·m
0.45 kgf-m
3.0 lb-ft
( )
( )
( )
