1.3. Accessories included
• SV 80 general purpose vibration accelerometer 100 mV/g (10 mV/ms
-2
)
• SA 27 mounting magnet for the accelerometer
• SC 27 TNC (plug) to TNC (plug) coil cable (2 m)
• SA 74 waterproof carrying case
• SC 56 USB cable
• SA 62 8 GB micro SD card
• SV 974_4 FFT analysis option
• four AA alkaline batteries
• SvanPC++ download and viewing software.
1.4. Accessories available
• SVRPM_PROB Laser Tachometer with SC 69 cable
• SA 47 carrying bag for SVAN 95x and accessories (fabric material)
• SA 54 Power supply unit by USB interface using cables SC 16 or SC 56 (cables not included)
• SA 31 external charger for four AA rechargeable batteries.
1.5. Software options available
• SV 974_1 1/1 & 1/3 octave analysis option
• SV 974_8 Rotation measurement option without Laser Tachometer
• SV 977_15 Time domain waveform signal recording (to the micro SD card: *.srt or *.wav format).
Note: The software options for the instrument can be purchased at any time as only the introduction
of a special unlock code is required for their activation in a specific instrument. Contact your local
Svantek distributor for further information and costs for these options.
1.6. General parameters
Input IEPE, Charge amplifier or Direct with TNC connector
IEPE Current Selectable: 1.5 mA, 3.0 mA, 4.5 mA
Dynamic Range More than 100 dB in single range
Internal Noise Level Less than 10 µV RMS (IEPE input & HP1 filter)
Frequency Range (-3 dB) 0.7 Hz ÷ 22.6 kHz, sampling rate 48 kHz
Display Colour OLED 2.4”, 320 x 240 pixels
Memory MicroSD flash card slot (supports 4 GB ÷ 16 GB cards)
Interfaces USB 1.1 Client, Extended I/O - AC output 1 V RMS Sine (1.41 V Peak) or Digital
Input/Output (Trigger - Pulse)
Power Supply Four AA batteries (alkaline) operation time > 12 h (6.0 V / 1.6 Ah)1
Four AA rechargeable batteries (not included) operation time > 16 h (4.8 V / 2.6
Ah)1
USB interface 500 mA HUB
Environmental Conditions Temperature from -10 oC to 50 oC
Humidity up to 90 % RH, non-condensed
Dimensions 140 x 83 x 33 mm (without accelerometer)
Weight Approx. 390 grams including batteries (without accelerometer)
