Symmetricom XL-GPS User Manual

6: Option Cards
Switch Position Signal Type
1 10 MPPS
2 5 MPPS
3 1 MPPS
4 100 kPPS
5 10 kPPS
6 1 kPPS
7 1 PPS
8 Time code
9 PPO
A Alarm
B-F Not Used
Note: PPO and Alarm relay are only available if those options have been purchased and are
enabled using F126 – Options Key Entry(page149).
Note: F90 – Code Output Configurationdoes not control the IRIG signals on the Expansion
Module.
Page 156 of 221 .................................098-00116-000 Rev. A
