SYNAPTICON SOMANET Node 400 User Manual

[IN] General
Purpose
2
[OUT] General
Purpose
3
[IN] Home Switch
(Active High)
4
[IN] Home Switch
(Active Low)
5
[IN] Limit Switch
Positive (Active
High)
6
[IN] Limit Switch
Positive (Active
Low )
7
[IN] Limit Switch
Negative (Active
High)
8
[IN] Limit Switch
Negative (Active
Low)
9
[IN] Interlock -
Disable Operation
(Active Low)
10
[IN] Fault Reset
(Active High)
11
[IN] Interlock -
Fault Reaction
(Active Low)
12
[IN] Timestamped
Rising Edge
(Active High)
13
[OUT] Target
Reached
14
[OUT] Internal
limit Active
15
[OUT]
Timestamped
Triggered Output
16
[OUT] Position
Triggered Output
(Pulse)
17
[OUT] Fault 18
[OUT] Switched
On
19
[OUT] Ready to
Switch On
20
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 724/887
