TechnipFMC Smith Meter AccuLoad III User Manual

Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 17
6-Product Meters (AccuLoad III-S Hardware Rev. 10.08 and above firmware
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Single Pulse
Meter #1A Meter #2A Meter #3A Meter #4A. Meter #5A. Meter #6A
Dual Pulse N/A N/A N/A N/A N/A N/A
Dual/Integrity
N/A N/A N/A N/A N/A N/A
5-Product Meters (AccuLoad III-S Hardware Rev. 10.08 and above firmware
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Single Pulse
Meter #1A Meter #2A Meter #3A Meter #4A. Meter #5A. Injector/Dens.
Dual Pulse N/A N/A N/A N/A N/A N/A
Dual/Integrity
N/A N/A N/A N/A N/A N/A
4-Product Meters (AccuLoad III-S Hardware Rev. 10.08 and above firmware
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Single Pulse
Meter #1A Meter #2A Meter #3A Meter #4A. Injector/Dens. Injector/Dens.
Dual Pulse N/A N/A N/A N/A N/A N/A
Dual/Integrity
N/A N/A N/A N/A N/A N/A
3-Product Meters (AccuLoad III-S Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Single Pulse
Meter #1A Meter #2A Meter #3A Injector/Dens. Injector/Dens. Injector/Dens.
Dual Pulse
Meter #1A Meter #1B Meter #3A Meter #2A Meter #2B Meter #3B
Dual/Integrity
N/A N/A N/A N/A N/A N/A
2-Product Meters (AccuLoad III-S Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Single Pulse
Meter #1A Meter #2A Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual Pulse
Meter #1A Meter #1B Injector/Dens. Meter #2A Meter #2B Injector/Dens.
Dual/Integrity
Meter #1A Meter #1B Meter #1A Bar Meter #2A Meter #2B Meter #2A Bar
1-Product Meter (AccuLoad III-S Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Single Pulse
Meter #1A Reserved Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual Pulse
Meter #1A Meter #1B Reserved Injector/Dens. Injector/Dens. Injector/Dens.
Dual/Integrity
Meter #1A Meter #1B Meter #1A Bar Injector/Dens. Injector/Dens. Injector/Dens.
Table 6. Pulse Inputs
Note: When using dual pulse and not the A Bar inputs for transmitter security, the pulse inputs for the A Bar assignment will be not used
