TechnipFMC Smith Meter AccuLoad III - AC Remote Start and Stop; DC Remote Start and Stop

Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 46
Figure 32. AC Remote Start and Stop
Figure 33. DC Remote Start and Stop
IN X+
IN X-
AccuLoad III - EAAI
AC Power
Supply
L1
Terminal Block TB2
Remote Stop or
Remote Start
(Momentary Contact)
L2 or
Neutral
