Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 67
Digital Inputs – AICB
Figure 55. Metered Injector / Pulse Transmitter Wiring Diagram
Figure 56. Metered Injector / Open Collector Wiring Diagram
METERED INJECTOR
OR
PULSE TRANSMITTER
AICB
+V
SIG
COMM
V+ (SELECTABLE)
SIG
COMM
Monoblock Additive Meter
METERED INJECTOR
OR
PULSE TRANSMITTER
AICB
SIG
COMM
Monoblock Additive Meter
