TechnipFMC Smith Meter AccuLoad III User Manual

Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 16
4-Product Meters (AccuLoad III-Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Single Pulse
Meter #1A Meter #2A Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual Pulse
Meter #1A Meter #1B Injector/Dens. Meter #2A Meter #2B Injector/Dens.
Dual/Integrity
Meter #1A Meter #1B Meter #1A Bar Meter #2A Meter #2B Meter #2A Bar
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Single Pulse
Meter #3A Meter #4A Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual Pulse
Meter #3A Meter #3B Injector/Dens. Meter #4A Meter #4B Injector/Dens.
Dual/Integrity
Meter #3A Meter #3B Meter #3A Bar Meter #4A Meter #4B Meter #4A Bar
3-Product Meters (AccuLoad III-Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Single Pulse
Meter #1A Meter #2A Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual Pulse
Meter #1A Meter #1B Injector/Dens. Meter #2A Meter #2B Injector/Dens.
Dual/Integrity
Meter #1A Meter #1B Meter #1A Bar Meter #2A Meter #2B Meter #2A Bar
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Single Pulse
Meter #3A Injector Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual Pulse
Meter #3A Meter #3B Injector/Dens. Reserved Reserved Injector/Dens.
Dual/Integrity
Meter #3A Meter #3B Meter #3A Bar Injector/Dens. Injector/Dens. Injector/Dens.
2-Product Meters (AccuLoad III-Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Single Pulse
Meter #1A Meter #2A Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual Pulse
Meter #1A Meter #1B Injector/Dens. Meter #2A Meter #2B Injector/Dens.
Dual/Integrity
Meter #1A Meter #1B Meter #1A Bar Meter #2A Meter #2B Meter #2A Bar
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Single Pulse
Injector Injector Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual Pulse
Injector Injector Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual/Integrity
Injector Injector Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
1-Product Meter (AccuLoad III-Q Hardware)
Input #1 Input #2 Input #3 Input #4 Input #5 Input #6
Single Pulse
Meter #1A Reserved Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual Pulse
Meter #1A Meter #1B Reserved Injector/Dens. Injector/Dens. Injector/Dens.
Dual/Integrity
Meter #1A Meter #1B Meter #1A Bar Injector/Dens. Injector/Dens. Injector/Dens.
Input #7 Input #8 Input #9 Input #10 Input #11 Input #12
Single Pulse
Injector Injector Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual Pulse
Injector Injector Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
Dual/Integrity
Injector Injector Injector/Dens. Injector/Dens. Injector/Dens. Injector/Dens.
