TechnipFMC Smith Meter AccuLoad III User Manual

Section VI – Completing the Installation
MN06135 Issue/Rev. 1.3 (6/17) 87
Figure 67. Flame path verification
Sealing
E
ach of the AccuLoad enclosures can be sealed using standard seal wires. On the AccuLoad S and Q models the
seal wire is threaded through holes in two cover bolts as shown in the following figures.
Feeler gauge test of cover flame path joint, inspect joint around the complete
perimeter using a 0.0015" (0.0381 mm) feeler gauge. (ALIV-Q shown - use the
same procedure for ALIV-S).
