TechnipFMC Smith Meter AccuLoad III User Manual

Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 70
Additive Pumps 1 through 4 are wired to the programmed terminals on the EAAI board. Additive Pumps 3 through
12 (AccuLoad III-S hardware) or Additive Pumps 5 through 24 (AccuLoad III-Q hardware) are wired per the following
table. Terminals are automatically assigned as additive pumps if metered injectors are programmed in the AccuLoad.
Additive Pumps (Optional AICB #1)
Additive Pump #
ALIII-S Hardware
ALIII-Q Hardware
Terminal +V
Terminal Block
5
5
10
TB8
6
6
8
TB8
7
7
6
TB8
8
8
4
TB8
9
9
2
TB8
10
10
10
TB7
11
11
8
TB7
12
12
6
TB7
13
13
4
TB7
14
14
2
TB7
Additive Pumps (Optional AICB #2)
N/A
15
10
TB8
N/A
16
8
TB8
N/A
17
6
TB8
N/A
18
4
TB8
N/A
19
2
TB8
N/A
20
10
TB7
N/A
21
8
TB7
N/A
22
6
TB7
N/A
23
4
TB7
N/A
24
2
TB7
Table 16. Additive Pumps (Optional AICB #1 and #2)
