TechnipFMC Smith Meter AccuLoad III - Wiring Terminals, Digital Inputs

Section IV – Diagrams
MN06135 Issue/Rev. 1.3 (6/17) 51
Wiring Terminals, Digital Inputs
Input # Voltage Type Board Terminal Block
Terminal
Input (+)
Connections
Common (-)
1 DC KDC TB4 1 2
2 DC KDC TB4 3 4
3 DC KDC TB4 5 6
4 DC EAAI TB4 5 4
5 DC EAAI TB4 7 6
6 DC EAAI TB4 9 8
7 AC EAAI TB2 2 1
8 AC EAAI TB2 3 1
9 AC EAAI TB2 4 1
10 AC EAAI TB2 5 1
11 AC EAAI TB2 6 1
12 AC BSE TB11 1 5
13 AC BSE TB11 2 5
14 AC BSE TB11 3 5
15 AC BSE TB11 4 5
Table 10. Digital Inputs
